SC-600N
|
SC-600S
|
|
sensor |
1/3" 270K Pixel
|
1/3" 410K Pixel
|
|
Picture elements |
510(H)×492(V)
|
510(H)×492(V)
|
|
Minimum illumination |
0.1 LUX ( F = 1.2 )
|
|
Backlight
compensation |
ON/OFF : manual
switching |
|
TV
system |
NTSC or PAL
|
|
Video
S/N ratio |
More than 46 dB
|
|
Horizontal resolution |
380 TV Line |
480 TV Line
|
|
Video
output level |
VBS 1.0 Vp-p 75¥Ø
|
|
Auto iris
type |
Video / Electronic
|
|
Power
requirement |
DC 12V ±10% 120mA
|
|
Lens
mount |
CS/C mount (C mount: using
C-mount adaptor supplied) |
|
Dimensions |
52(W)×60(H)×118(D)mm
|
|
Weight |
300g |
|
|
|
|
SDC-400N
|
SDC-400S
|
|
sensor |
1/3" 270K Pixel
|
1/3" 410K Pixel
|
|
Picture elements |
510(H)×492(V)
|
768(H)×494(V)
|
|
Minimum illumination |
0.2 LUX ( F = 1.2 )
|
|
Lens
|
f = 3.6mm
|
|
TV
system |
NTSC |
|
Video
S/N ratio |
More than 46 dB
|
|
Horizontal resolution |
380 TV Line |
480 TV Line
|
|
Video
output level |
VBS 1.0 Vp-p 75¥Ø
|
|
Connector
|
BNC Type
|
|
Power
requirement |
DC 12V ±10% 120mA
|
|
Environmental condition |
-20¡É ¡ +60¡É
|
|
Dimensions |
97(W)×59(H)mm
|
|
Weight |
114g |
|
|
|
|
|
SDC-300C
|
|
sensor |
1/3" 270K Pixel
|
|
Picture elements |
768(H)×494(V)
|
|
Minimum illumination |
0.2 LUX ( F = 1.4 )
|
|
Lens / Angle of
view |
f = 3.6mm / 92°
|
|
TV
system |
NTSC |
|
Video
S/N ratio |
More than 46 dB
|
|
Horizontal resolution |
480 TV Line
|
|
Video
output level |
VBS 1.0 Vp-p 75¥Ø
|
|
Connector
|
Terminals
|
|
Power
requirement |
DC 12V ±10% 130mA
|
|
Environmental condition |
-20¡É ¡ +60¡É
|
|
Dimensions |
120(W)×80(H)mm
|
|
Weight |
215g |
|
|
|
|
|
SC-500B
|
|
sensor |
1/3" 270K Pixel
|
|
Picture elements |
537(H)×505(V)
|
|
Minimum illumination |
0.1 LUX ( F = 1.2 )
|
|
Backlight
compensation |
ON/OFF : manual
switching |
|
TV
system |
NTSC or PAL
|
|
Video
S/N ratio |
More than 46 dB
|
|
Horizontal resolution |
380 TV Line
|
|
Video
output level |
VBS 1.0 Vp-p 75¥Ø
|
|
Auto iris
type |
Video / Electronic
|
|
Power
requirement |
DC 12V ±10% 120mA
|
|
Environmental condition |
-20¡É ¡ +60¡É
|
|
Dimensions |
52(W)×60(H)×118(D)mm
|
|
Weight |
300g |
|
|
|
|
|
SDC-400B
|
|
sensor |
1/3" 270K Pixel
|
|
Picture elements |
537(H)×505(V)
|
|
Minimum illumination |
0.2 LUX ( F = 1.2 )
|
|
Lens
|
f = 3.6mm
|
|
TV
system |
NTSC or PAL
|
|
Video
S/N ratio |
More than 50dB
|
|
Horizontal resolution |
380 TV Line
|
|
Video
output level |
VBS 1.0 Vp-p 75¥Ø
|
|
Connector
|
BNC Type
|
|
Power
requirement |
DC 9V ±10% 220mA
|
|
Environmental condition |
-20¡É ¡ +60¡É
|
|
Dimensions |
97(W)×59(H)mm
|
|
Weight |
114g |
|
|
|
|
|
SDC-300B
|
|
sensor |
1/3" 270K Pixel
|
|
Picture elements |
510(H)×492(V)
|
|
Minimum illumination |
0.2 LUX ( F = 1.4 )
|
|
Lens / Angle of
view |
f = 3.6mm / 92°
|
|
TV
system |
NTSC or PAL
|
|
Video
S/N ratio |
More than 46 dB
|
|
Horizontal resolution |
380 TV Line
|
|
Video
output level |
VBS 1.0 Vp-p 75¥Ø
|
|
Connector
|
Terminals
|
|
Power
requirement |
DC 12V ±10% 130mA
|
|
Environmental condition |
-20¡É ¡ +60¡É
|
|
Dimensions |
120(W)×80(H)mm
|
|
Weight |
215g |
|
|
|
